HomeShopRadiatorsCSF 7012T High-Performance All-Aluminum Radiator for Nissan 370Z and Infiniti G37
Sale
CSF 7012T High-Performance All-Aluminum Radiator for Nissan 370Z and Infiniti G37
CSF 7012T High-Performance All-Aluminum Radiator for Nissan 370Z and Infiniti G37 - Image 2
CSF 7012T High-Performance All-Aluminum Radiator for Nissan 370Z and Infiniti G37 - Image 3
CSF 7012T High-Performance All-Aluminum Radiator for Nissan 370Z and Infiniti G37 - Image 4
CSF 7012T High-Performance All-Aluminum Radiator for Nissan 370Z and Infiniti G37 - Image 5
CSF 7012T High-Performance All-Aluminum Radiator for Nissan 370Z and Infiniti G37 - Image 6
CSF 7012T High-Performance All-Aluminum Radiator for Nissan 370Z and Infiniti G37 - Image 7
CSF 7012T High-Performance All-Aluminum Radiator for Nissan 370Z and Infiniti G37 - Image 8
CSF 7012T High-Performance All-Aluminum Radiator for Nissan 370Z and Infiniti G37 - Image 9
CSF 7012T High-Performance All-Aluminum Radiator for Nissan 370Z and Infiniti G37 - Image 10

CSF 7012T High-Performance All-Aluminum Radiator for Nissan 370Z and Infiniti G37

SKU: 7012T

Original price was: $709.00.Current price is: $655.00.

In stock

11 in stock

CSF has over 5 decades of experience manufacturing radiators. So when it comes to keeping your engine cool and your 370Z/G37 running at its best, a CSF High-Performance All-Aluminum Radiator is the obvious choice. Designed to perform on the street or at the track, a performance radiator is a must-have for both high horsepower builds as well as race vehicles which need added cooling performance in motorsports environments. The Triple-Pass Flow Structure allows the coolant to flow across the core of the radiator three times before exiting for lowest outlet temperatures possible. This radiator features a 2-Row core with CSF's exclusive B-Tube Technology: Unlike a regular oval shape "O" type radiator tube, CSF uses a specially engineered tube in the shape of a "B". These "B-tubes" are carefully formed and then brazed over the seam to seal. CSF is able to use thinner and lighter aluminum material (with better cooling efficiency) because this design is actually stronger than normal "O" shape tubes that are welded. The design (inlet in the middle of the tube that is seam brazed) increases the heat transfer surface area of the tubes by approximately 15% over regular tubes - producing the efficiency of two smaller tubes vs. one large tube within the same space criteria. With "B-tubes" you are able to get "dual liquid laminar flow". CSF also uses ultra efficient multi louvered fins that are carefully and precisely aligned to maximize airflow through each radiator core. Fin specifications are carefully measured and calculated for each application, and tested for maximum heat rejection efficiency in our wind-tunnel lab. CSF manufactures the most advanced and efficient radiator in the industry for your 370Z/G37. CSF uses innovative tube and fin technologies with industry-leading testing methods to maximize airflow and heat dissipation. The CSF #7012T Cooling product is designed to be a "Drop-In Fit" application. The product will install in the OEM Location with no modifications necessary unless otherwise noted or instructions are included in the product package. Please see the manufacturer repair manual for standard installation instructions. If you do not feel confident installing this product CSF recommends taking it to a qualified installation facility.
  • "Drop-in Fit" Requiring No Modifications to Install - Accepts All Attaching OEM Components Including "Quick Connect" Hoses, AC Condenser, Mounting Brackets and Fan Shroud
  • Core Features an Ultra-Efficient Fin with 6.5mm Fin Height and Multi-Louvered Design for Maximum Surface Area Contact
  • 2-Row 42mm Core (Dual Core) Featuring CSF's Exclusive B-Tube Technology
  • CNC Machined Brackets and Fittings for Superb Fit and Durability
  • CNC Machined "Quick-Connect" Inlet/Outlet Connections
  • Includes both the Radiator and AC Condenser
  • All-Aluminum Race Style Drain Plug
  • Triple-Pass Radiator Design
  • Smooth Satin Finish
Buy now
Add to wishlist Add to compare
Category: Tags: ,

Description

The CSF 7012T high-performance radiator is engineered for optimal cooling in Nissan 370Z and Infiniti G37 models, offering a reliable upgrade for street and track driving. With over five decades of experience, CSF manufactures radiators that combine innovative technology and rigorous testing to ensure maximum efficiency and durability. This radiator features a dual-row, 42mm core with CSF’s exclusive B-Tube Technology, which enhances heat transfer surface area by approximately 15%, resulting in superior cooling performance compared to traditional designs. The B-tube shape, brazed over the seam, allows for thinner, lighter aluminum usage while maintaining strength, making the radiator both efficient and robust. Its triple-pass flow structure ensures coolant passes through the core three times, reducing outlet temperatures significantly and providing consistent engine cooling under high-performance conditions. The use of ultra-efficient multi-louvered fins aligned precisely maximizes airflow and heat dissipation, tested in wind-tunnel environments to guarantee optimal maximum heat rejection. This radiator is a direct-fit replacement, designed for easy installation without modifications, accepting all OEM components including quick connect hoses, mounting brackets, the AC condenser, and fan shroud. Crafted with CNC-machined brackets and fittings, it offers a perfect fit and long-lasting durability. The CSF #7012T includes both the radiator and AC condenser, finished with a smooth satin coating for corrosion resistance and aesthetic appeal. Whether for high horsepower builds or track racing, this radiator delivers industry-leading cooling performance, ensuring your vehicle runs at its best even in demanding conditions.

Features:

  • Drop-in fit design requiring no modifications for easy installation
  • Accepts all OEM components including quick connect hoses and mounting brackets
  • Dual-row 42mm core with CSF’s exclusive B-Tube Technology for enhanced heat transfer
  • Triple-pass flow structure for maximum cooling efficiency
  • Ultra-efficient multi-louvered fins aligned for optimal airflow and heat dissipation
  • CNC-machined brackets and fittings ensuring precise fit and durability
  • Includes radiator and AC condenser for comprehensive cooling solution
  • All-aluminum construction with satin finish for corrosion resistance and aesthetics
  • High-performance drain plug suitable for racing environments

Fitment:
Infiniti G35 Base 2007
Infiniti G35 Base 2008
Infiniti G35 Journey 2007
Infiniti G35 Journey 2008
Infiniti G35 Sport 2007
Infiniti G35 Sport 2008
Infiniti G35 X 2007
Infiniti G35 X 2008
Infiniti G37 Base 2008
Infiniti G37 Base 2009
Infiniti G37 Base 2010
Infiniti G37 Base 2011
Infiniti G37 Base 2012
Infiniti G37 Base 2013
Infiniti G37 IPL 2011
Infiniti G37 IPL 2012
Infiniti G37 IPL 2013
Infiniti G37 Journey 2008
Infiniti G37 Journey 2009
Infiniti G37 Journey 2010
Infiniti G37 Journey 2011
Infiniti G37 Journey 2012
Infiniti G37 Journey 2013
Infiniti G37 Sport 2008
Infiniti G37 Sport 2009
Infiniti G37 Sport 2010
Infiniti G37 Sport 2011
Infiniti G37 Sport 2012
Infiniti G37 Sport 2013
Infiniti G37 X 2009
Infiniti G37 X 2010
Infiniti G37 X 2011
Infiniti G37 X 2012
Infiniti G37 X 2013
Infiniti Q60 Base 2014
Infiniti Q60 Base 2015
Infiniti Q60 IPL 2014
Infiniti Q60 IPL 2015
Infiniti Q60 Journey 2014
Infiniti Q60 Journey 2015
Infiniti Q60 S 2014
Infiniti Q60 S 2015
Infiniti Q60 S Limited 2015
Nissan 370Z 40th Anniversary Edition 2010
Nissan 370Z Base 2009
Nissan 370Z Base 2010
Nissan 370Z Base 2011
Nissan 370Z Base 2012
Nissan 370Z Base 2013
Nissan 370Z Base 2014
Nissan 370Z Base 2015
Nissan 370Z Base 2016
Nissan 370Z Base 2017
Nissan 370Z Base 2018
Nissan 370Z Base 2019
Nissan 370Z Base 2020
Nissan 370Z Heritage Edition 2018
Nissan 370Z Heritage Edition 2019
Nissan 370Z Nismo 2009
Nissan 370Z Nismo 2010
Nissan 370Z Nismo 2011
Nissan 370Z Nismo 2012
Nissan 370Z Nismo 2013
Nissan 370Z Nismo 2014
Nissan 370Z Nismo 2015
Nissan 370Z Nismo 2016
Nissan 370Z Nismo 2017
Nissan 370Z Nismo 2019
Nissan 370Z Nismo 2020
Nissan 370Z Nismo Tech 2015
Nissan 370Z Nismo Tech 2016
Nissan 370Z Nismo Tech 2017
Nissan 370Z Nismo Tech 2018
Nissan 370Z Sport 2015
Nissan 370Z Sport 2016
Nissan 370Z Sport 2017
Nissan 370Z Sport 2018
Nissan 370Z Sport 2019
Nissan 370Z Sport 2020
Nissan 370Z Sport Tech 2015
Nissan 370Z Sport Tech 2016
Nissan 370Z Sport Tech 2017
Nissan 370Z Sport Tech 2018
Nissan 370Z Sport Touring 2019
Nissan 370Z Sport Touring 2020
Nissan 370Z Touring 2009
Nissan 370Z Touring 2010
Nissan 370Z Touring 2011
Nissan 370Z Touring 2012
Nissan 370Z Touring 2013
Nissan 370Z Touring 2014
Nissan 370Z Touring 2015
Nissan 370Z Touring 2016
Nissan 370Z Touring 2017
Nissan 370Z Touring 2018
Nissan 370Z Touring 2019
Nissan 370Z Touring Sport 2015
Nissan 370Z Touring Sport 2016
Nissan 370Z Touring Sport 2017
Nissan 370Z Touring Sport 2018

Additional information

Weight 23 lbs
Dimensions 36.4 × 22 × 11.4 in
air_freight_prohibited

false
not_carb_approved

false
ltl_freight_required

false
prop_65

N
part_type

automotive
epa

N/A
carb_acknowledgement_required

false
regular_stock

t
upc

710353070123
brand

CSF
part_number

7012T
