CSF High-Performance All-Aluminum Radiator for Ford Mustang 2007-2014 (Part #7037)
CSF High-Performance All-Aluminum Radiator for Ford Mustang 2007-2014 (Part #7037) - Image 2
CSF High-Performance All-Aluminum Radiator for Ford Mustang 2007-2014 (Part #7037) - Image 3
CSF High-Performance All-Aluminum Radiator for Ford Mustang 2007-2014 (Part #7037) - Image 4
CSF High-Performance All-Aluminum Radiator for Ford Mustang 2007-2014 (Part #7037) - Image 5
CSF High-Performance All-Aluminum Radiator for Ford Mustang 2007-2014 (Part #7037) - Image 6
CSF High-Performance All-Aluminum Radiator for Ford Mustang 2007-2014 (Part #7037) - Image 7
CSF High-Performance All-Aluminum Radiator for Ford Mustang 2007-2014 (Part #7037) - Image 8
CSF High-Performance All-Aluminum Radiator for Ford Mustang 2007-2014 (Part #7037) - Image 9
CSF High-Performance All-Aluminum Radiator for Ford Mustang 2007-2014 (Part #7037) - Image 10

CSF High-Performance All-Aluminum Radiator for Ford Mustang 2007-2014 (Part #7037)

SKU: 7037

Original price was: $599.00.Current price is: $539.00.

In stock

5 in stock

CSF has over 5 decades of experience manufacturing radiators. So when it comes to keeping your engine cool and your Mustang running at its best, a CSF High-Performance All-Aluminum Radiator is the obvious choice. Designed to perform on the street or at the track, a performance radiator is a must-have for both high horsepower builds as well as race vehicles which need added cooling performance in motorsports environments. This radiator features a 2-Row core with CSF's exclusive B-Tube Technology: Unlike a regular oval shape "O" type radiator tube, CSF uses a specially engineered tube in the shape of a "B". These "B-tubes" are carefully formed and then brazed over the seam to seal. CSF is able to use thinner and lighter aluminum material (with better cooling efficiency) because this design is actually stronger than normal "O" shape tubes that are welded. The design (inlet in the middle of the tube that is seam brazed) increases the heat transfer surface area of the tubes by approximately 15% over regular tubes - producing the efficiency of two smaller tubes vs. one large tube within the same space criteria. With "B-tubes" you are able to get "dual liquid laminar flow". CSF also uses ultra efficient multi louvered fins that are carefully and precisely aligned to maximize airflow through each radiator core. Fin specifications are carefully measured and calculated for each application, and tested for maximum heat rejection efficiency in our wind-tunnel lab. CSF manufactures the most advanced and efficient radiator in the industry for your Mustang. CSF uses innovative tube and fin technologies with industry-leading testing methods to maximize airflow and heat dissipation. The CSF #7037 Cooling product is designed to be a "Drop-In Fit" application. The product will install in the OEM Location with no modifications necessary unless otherwise noted or instructions are included in the product package. Please see the manufacturer repair manual for standard installation instructions. If you do not feel confident installing this product CSF recommends taking it to a qualified installation facility.
  • "Drop-in Fit" Requiring No Modifications to Install - Accepts All Attaching OEM Components Including "Quick Connect" Hoses, AC Condenser, Mounting Brackets and Fan Shroud
  • Core Features an Ultra-Efficient Fin with 6.5mm Fin Height and Multi-Louvered Design for Maximum Surface Area Contact
  • 2-Row 42mm Core (Dual Core) Featuring CSF's Exclusive B-Tube Technology
  • CNC Machined Brackets and Fittings for Superb Fit and Durability
  • CNC Machined "Quick-Connect" Inlet/Outlet Connections
  • All-Aluminum Race Style Drain Plug
  • 1-Hour "Mirror Finish" Hand Polish
Buy now
Add to wishlist Add to compare
Category: Tags: ,

Description

The CSF #7037 High-Performance All-Aluminum Radiator is engineered to optimize cooling efficiency for your Ford Mustang from model years 2007 through 2014. Built with over five decades of expertise, CSF’s radiator features a durable 2-Row core utilizing exclusive B-Tube Technology, which enhances heat transfer and strength compared to conventional oval tubes. This innovative tube design increases surface area by approximately 15%, facilitating superior heat dissipation and dual liquid laminar flow for improved cooling performance during street driving or high-performance racing. The radiator’s ultra-efficient multi-louvered fins, with a fin height of 6.5mm, are precisely aligned to maximize airflow and maximize heat rejection, ensuring your engine remains at optimal temperatures under demanding conditions.
Designed as a direct drop-in replacement, the CSF #7037 radiator requires no modifications for installation and accepts all OEM components, including quick-connect hoses, the AC condenser, mounting brackets, and fan shroud. The radiator features CNC machined brackets and fittings for a perfect fit and enhanced durability, along with a race-style all-aluminum drain plug for reliable maintenance. The product is finished with a 1-hour mirror polish, providing a sleek, corrosion-resistant surface that complements your vehicle’s engine bay. Whether for daily driving or track use, this radiator delivers industry-leading cooling technology, ensuring your Mustang maintains peak performance without the need for extensive modifications.

Features:

  • Drop-in fit design requiring no modifications for easy installation
  • Accepts all OEM components including quick-connect hoses and mounting brackets
  • 2-Row 42mm core with exclusive B-Tube technology for enhanced strength and heat transfer
  • Ultra-efficient multi-louvered fins with 6.5mm fin height for maximum surface contact
  • CNC machined brackets and fittings for precise fit and durability
  • All-aluminum race-style drain plug for reliable maintenance
  • 1-hour mirror finish hand polish for corrosion resistance and aesthetic appeal

Fitment:
Ford Mustang Base 2005
Ford Mustang Base 2006
Ford Mustang Base 2007
Ford Mustang Base 2008
Ford Mustang Base 2009
Ford Mustang Base 2010
Ford Mustang Base 2011
Ford Mustang Base 2012
Ford Mustang Base 2013
Ford Mustang Base 2014
Ford Mustang Boss 302 2012
Ford Mustang Boss 302 2013
Ford Mustang Bullitt 2008
Ford Mustang Bullitt 2009
Ford Mustang GT 2005
Ford Mustang GT 2006
Ford Mustang GT 2007
Ford Mustang GT 2008
Ford Mustang GT 2009
Ford Mustang GT 2010
Ford Mustang GT 2011
Ford Mustang GT 2012
Ford Mustang GT 2013
Ford Mustang GT 2014
Ford Mustang Shelby GT 2007
Ford Mustang Shelby GT 2008
Ford Mustang Shelby GT500 2007
Ford Mustang Shelby GT500 2008
Ford Mustang Shelby GT500 2009
Ford Mustang Shelby GT500 2010
Ford Mustang Shelby GT500 2011
Ford Mustang Shelby GT500 2012
Ford Mustang Shelby GT500 2013
Ford Mustang Shelby GT500KR 2008
Ford Mustang Shelby GT500KR 2009

Additional information

Weight 21.5 lbs
Dimensions 32 × 24.5 × 8.3 in
air_freight_prohibited

false
not_carb_approved

false
ltl_freight_required

false
prop_65

N
part_type

automotive
epa

N/A
carb_acknowledgement_required

false
regular_stock

t
upc

710353070376
brand

CSF
part_number

7037
