HomeShopLeaf Springs & AccessoriesICON 2017+ Ford Raptor Multi-Rate Leaf Pack with Add-In Leaf – Improved Ride and Load Capacity
ICON 2017+ Ford Raptor Multi-Rate Leaf Pack with Add-In Leaf - Improved Ride and Load Capacity
ICON 2017+ Ford Raptor Multi-Rate Leaf Pack with Add-In Leaf - Improved Ride and Load Capacity - Image 2

ICON 2017+ Ford Raptor Multi-Rate Leaf Pack with Add-In Leaf – Improved Ride and Load Capacity

SKU: 198510

$727.05

In stock

48 in stock

To fully take advantage of ICON’s current 2017-2020 F150 Raptor offerings, ICON engineers decided to scrap the OE leaf springs and develop a replacement that addressed a couple issues found in the R&D process. The result is a user-adjustable multi-rate leaf pack that offers a major performance gain for almost every Raptor setup imaginable. To increase the ride quality of the truck and gain additional droop travel, the spring rate was designed to be slightly lighter than factory, which was found to be on the stiff side for smaller, choppier terrain. While most Raptor owners will embrace the improved ride quality this provides, there are those who have outfitted their trucks with a significant amount of weight and require more load carrying capability. Understanding this, ICON engineers designed the leaf pack with an additional leaf (included with kit) that can be exchanged or added to the pack, yielding an additional 20% or 40% spring rate that will work well for heavier vehicles. 2017-2020 FORD RAPTOR MULTI RATE LEAF PACK WITH ADD IN LEAF TECH NOTE: Not compatible with some aftermarket leaf spring shackles. Stock or ICON 1" lowering shackles are recommended. ICON 1" Lowering Shackles, part number 91001, are recommended for most 2021-2024 F-150 applications unless taller lift heights are required.
  • “ICON 1K” tested under rigorous off-road conditions to validate tune, performance, strength, and durability
  • Leaf separators and tip inserts reduce noise and friction while increasing ride comfort
  • Triple military wrap front eyelet and rear half wrap for increased durability
  • Direct bolt-in to OEM spring location makes for an easy install
  • 3 user-adjustable spring rates for unique vehicle setups
  • Rebound leaf reduces severe axle wrap
Buy now
Add to wishlist Add to compare
Category: Tags: ,

Description

Enhance your Ford F-150 Raptor’s performance with the ICON 2017+ Ford Raptor Multi-Rate Leaf Pack featuring an add-in leaf. Designed by ICON engineers as a replacement for the OE leaf springs, this upgrade addresses common ride quality issues and offers a versatile solution for a wide range of Raptor setups. The leaf pack’s innovative design includes a user-adjustable configuration, allowing for three different spring rates to customize your vehicle’s handling, payload capacity, and ride comfort. The lighter-than-stock spring rate improves droop travel and ride quality on uneven terrain, making it ideal for off-road adventures and daily driving alike. For owners requiring additional load capacity, an extra leaf (included in the kit) can be added or exchanged to increase the spring rate by 20% or 40%, accommodating heavier vehicle modifications or payloads.

The ICON leaf pack is crafted with durability and performance in mind. Features such as triple military wrap front eyelets and rear half wrap enhance strength and longevity under demanding conditions. Leaf separators and tip inserts reduce noise and friction, resulting in a smoother ride and quieter operation. The design integrates seamlessly with OEM spring locations, ensuring a straightforward bolt-in installation without the need for modifications. The rebound leaf component helps mitigate axle wrap, maintaining stability during aggressive driving and off-road maneuvers. Tested rigorously under off-road conditions, the ICON 1K certification validates its performance, strength, and durability, making it a reliable upgrade for serious enthusiasts.

This leaf pack is compatible with 2017 through 2021 Ford F-150 Raptor models. For optimal installation, stock or ICON 1

Fitment:
Ford F-150 King Ranch 2021
Ford F-150 King Ranch 2022
Ford F-150 King Ranch 2023
Ford F-150 Lariat 2021
Ford F-150 Lariat 2022
Ford F-150 Lariat 2023
Ford F-150 Lariat 2024
Ford F-150 Platinum 2021
Ford F-150 Platinum 2022
Ford F-150 Platinum 2023
Ford F-150 Raptor 2017
Ford F-150 Raptor 2018
Ford F-150 Raptor 2019
Ford F-150 Raptor 2020
Ford F-150 Raptor 2021
Ford F-150 STX 2024
Ford F-150 Tremor 2021
Ford F-150 Tremor 2022
Ford F-150 Tremor 2023
Ford F-150 Tremor 2024
Ford F-150 XL 2021
Ford F-150 XL 2022
Ford F-150 XL 2023
Ford F-150 XL 2024
Ford F-150 XLT 2021
Ford F-150 XLT 2022
Ford F-150 XLT 2023
Ford F-150 XLT 2024

Additional information

Weight 54.1 lbs
Dimensions 60.1 × 15.2 × 3.1 in
air_freight_prohibited

false
not_carb_approved

false
ltl_freight_required

false
prop_65

Y
part_type

automotive
epa

N/A
carb_acknowledgement_required

false
regular_stock

t
upc

00840103408880
brand

ICON
part_number

198510
