ICON Hydraulic Bump Stop Kit for Ford Raptor 2010-2014 – Part K93052

ICON Hydraulic Bump Stop Kit for Ford Raptor 2010-2014 – Part K93052

SKU: K93052

$9,007.73

In stock

1 in stock

ICON's hydraulic bump stop uses oil and nitrogen to do two tasks: function as a spring and a shock. An internal nitrogen charge is compressed when the air bump is compressed to act as a spring, similar to the OEM bump stop. The difference is hydraulic air bumps are adjustable and can be tuned to have low impact forces at the beginning of the travel, and ramp theoretically to infinity at the end. Unlike the factory bump stop, ICON's hydraulic bump stop incorporates oil along with a damping piston internally to control the amount of energy that is returned to the suspension, reducing the vehicles tendency to kick. The oil and damping piston also control the compression of the air bump relative to speed which is important for Raptors hitting obstacles at extreme speeds. Our resulting dynamic system is one that is soft and compliant allowing full suspension travel at slow speeds, yet at high speeds will create very high forces to resist bottoming out. ICON's Ford Raptor hydraulic bump stop system uses a 2.5" travel air bump allowing the shock additional distance to control energy, and does not interfere with suspension travel under normal driving conditions. The clamshell bracket design with triangulated cross braces not only gives a rigid mounting point for the air bump, it helps support a known weak part of the frame prone to failure. 2010-2014 FORD RAPTOR STAGE 2 SUSPENSION SYSTEM Ships in multiple boxes
Buy now
Add to wishlist Add to compare
Category: Tags: ,

Description

The ICON Hydraulic Bump Stop Kit (Part K93052) is designed specifically for Ford Raptor models from 2010 to 2014, providing enhanced suspension performance and durability. This system employs a unique combination of oil and nitrogen to function as both a spring and a shock absorber, ensuring smooth handling across varied terrains. An internal nitrogen charge compresses during suspension travel, mimicking OEM bump stops, but with the added benefit of adjustability. This feature allows users to tune impact forces for optimal comfort and control, especially when navigating obstacles at high speeds.

The hydraulic design incorporates oil and a damping piston, which work together to regulate energy transfer and control compression rates based on vehicle speed. This results in a suspension system that remains compliant at slow speeds, allowing full travel and ride comfort, while providing high resistance to bottoming out during aggressive driving. The 2.5-inch travel air bump offers additional control distance, ensuring the suspension can manage energy effectively without interfering with normal driving conditions.

Constructed with a robust clamshell bracket featuring triangulated cross braces, the kit not only provides a secure mounting point but also reinforces a known weak area of the vehicle frame prone to failure. This design enhances overall suspension integrity and durability, making it a reliable upgrade for off-road enthusiasts seeking improved bump control and suspension performance. The ICON Hydraulic Bump Stop Kit is ideal for those looking to optimize their Ford Raptor’s handling, especially during high-impact scenarios, and offers a professional-grade solution that enhances both ride quality and vehicle longevity.

Features:

  • Oil and nitrogen charged for dual spring and shock function
  • Adjustable impact forces for customized tuning
  • Hydraulic damping piston controls energy return and compression speed
  • 2.5-inch travel air bump for additional suspension control
  • Robust clamshell mounting bracket with triangulated braces for frame reinforcement
  • Designed specifically for Ford Raptor models from 2010 to 2014

Fitment:
Ford F-150 SVT Raptor 2010
Ford F-150 SVT Raptor 2011
Ford F-150 SVT Raptor 2012
Ford F-150 SVT Raptor 2013
Ford F-150 SVT Raptor 2014

Additional information

air_freight_prohibited

false
not_carb_approved

false
ltl_freight_required

false
prop_65

Y
part_type

automotive
epa

N/A
carb_acknowledgement_required

false
regular_stock

t
brand

ICON
part_number

K93052
